Heavy-duty three-phase AC induction motor designed for reliable and continuous operation in industrial machinery and power-transmission applications. The motor provides efficient conversion of electrical energy into mechanical rotational power and is suitable for driving pumps, fans, compressors, conveyors, gearboxes and other rotating equipment.
Parameter Specification
Product Electric Motor
Motor Type Three-Phase AC Induction Motor
Rotor Type Squirrel Cage
Rated Power As required / To be confirmed
Rated Voltage 380–415 V AC
Frequency 50 Hz
Phase 3 Phase
Rated Speed As required, typically 1, 450 / 2, 900 RPM
Number of Poles 4 / 2 Pole
Efficiency Class IE3 or higher
Protection Rating IP55
Insulation Class Class F
Cooling Method TEFC / IC411
Mounting IEC B3 foot mounted, unless otherwise specified
Frame Size As required by motor power and installation
Duty S1 – Continuous Duty
Frame Material Cast Iron / Aluminium, depending on frame size
Bearings Heavy-duty anti-friction bearings
Standards IEC 60034
Application Industrial machinery, pumps, fans, conveyors, compressors and drives
