A hydraulic pressure switch with a display is an electronic, solid-state device that measures pressure, shows it on a digital screen, and controls circuits by activating switches at set points. A hydraulic pressure switch with display is a device used to monitor and control pressure in hydraulic systems.
It measures the pressure of hydraulic fluid and displays the value in real time on a digital screen.
The switch activates or deactivates electrical contacts when the preset pressure level is reached.
It helps protect hydraulic equipment from overpressure or low-pressure conditions.
The built-in display allows easy reading and monitoring without additional instruments.
These switches are commonly used in industrial machinery, presses, and automation systems.
They offer adjustable set points for flexible operation based on system requirements.
Many models include features like programmable settings and alarm indications.
The device is designed for durability and can withstand harsh working environments.
Overall, a hydraulic pressure switch with display ensures safe, accurate, and efficient pressure control.
Pressure Range 0 to 600 bar
Output Type PNP
Contact Type PNP 2 ouput with 4-20 ma output
Display LED
Body Material Stainless Steel
Supply Voltage 18–30 V DC
Setpoint Type adjustable set point
Process Connection G1/2
Max Fluid Temp 100°C
Enclosure Rating IP67
WIKA MAKE OEM PRESSURE SWITCH WITH DISPLAY
MODEL:PSD-4-ECO WITH 5 MTR M-12 CONNECTOR CABLE
OUTPUT SIGNAL: TWO SWITCHING OUTPUTS (PNP) + 4...20 MA
IO-LINK: WITHOUT, POWER SUPPLY: 15 ... 32 V DC
MEASURING RANGE: 0 TO 25 BAR
PROCESS CONNECTION: G1/2 B EN837
SEALING: COPPER, PERMISSIBLE MEDIUM TEMPERATURE: -25...+85°C
ELECTRICAL CONNECTION: CIRCULAR CONNECTOR M12X1, 5-PIN
PIN ASSIGNMENT: U+=1, SP2=2, U-=3, SP1=4, S+=5
OVERLOAD SAFETY: 2 X, ACCURACY: 1.0% OF SPAN With MODEL:PSD-4-ECO WITH 5 MTR M-12 CONNECTOR CABLEOUTPUT SIGNAL: TWO SWITCHING OUTPUTS (PNP) + 4...20 MAIO-LINK: WITHOUT, POWER SUPPLY: 15 ... 32 V DCMEASURING RANGE: 0 TO 25 BARPROCESS CONNECTION: G1/2 B EN837PERMISSIBLE MEDIUM TEMPERATURE: -40...+125°C..
